SP Machining 2021+ Ford F-150 Predator Supercharger Swap Kit (SPM-SAK-003)
The SP Machining Predator Supercharger Swap Kit provides a comprehensive solution for installing a Ford Predator supercharger on a 2021+ Ford F-150 equipped with the Gen 4 5.0L Coyote engine. Developed in partnership with OZ Tuning, this kit features billet aluminum intake adapters and nearly all the supporting components needed to retrofit a GT500 or Raptor R supercharger head unit.
Designed for a 100% bolt-on supercharger installation, the kit includes a 6-rib front-end accessory drive (FEAD) system, modified VMP Predator fuel rails, intercooler cooling components, fuel injectors, spark plugs, and additional installation hardware.
Predator Supercharger Compatibility
The billet aluminum intake adapters are designed to accommodate Predator supercharger head units from the Ford Mustang Shelby GT500 and Ford F-150 Raptor R on the 2021+ F-150 Gen 4 Coyote engine.
SP Machining developed this conversion to provide a straightforward and affordable alternative to sourcing and adapting individual supercharger installation components.
Complete 6-Rib FEAD System
The kit includes a 6-rib front-end accessory drive system designed to support the Predator supercharger conversion. Components include a balancer, A/C clutch, idlers, tensioner, and supercharger hub.
These components provide the accessory drive hardware needed for the supercharger installation.
Fuel System and Intercooler Components
SP Machining includes modified VMP Predator fuel rails designed for the 2021+ F-150, along with 55 lb/hr fuel injectors to support the supercharged engine configuration.
A heat exchanger and Bosch intercooler pump are also included to support the supercharger's charge-air cooling system.
The kit also supplies Ford Performance spark plugs, a MAP sensor and extension harness, and a 3.5-inch supercharger pulley.
Tested Performance
SP Machining reports the following wheel horsepower and torque results using a 3.5-inch supercharger pulley:
- 93 Octane: 588 wheel horsepower and 493 lb-ft of torque
- E85: 652 wheel horsepower and 520 lb-ft of torque
The included 3.5-inch pulley is reported to produce approximately 10-11 psi of boost, depending on climate conditions.
Actual horsepower, torque, and boost levels may vary depending on vehicle configuration, fuel, tuning, and environmental conditions. E85 operation requires additional fuel system upgrades.
OZ Tuning Partnership
Developed in partnership with OZ Tuning, this kit can be paired with an optional OZ forced induction tune. SP Machining advertises a $100 savings when adding an OZ forced induction tune to the purchase.
OZ forced induction tuning is available exclusively through HP Tuners. SCT devices are not supported for OZ forced induction applications.
Features
- Designed for 2021+ Ford F-150 5.0L Gen 4 Coyote engines
- Allows installation of compatible Ford Predator superchargers
- Works with GT500 and Raptor R supercharger head units
- Billet aluminum intake adapters for a 100% bolt-on conversion
- Developed in partnership with OZ Tuning
- Includes intake adapter mounting hardware and O-rings
- Complete 6-rib FEAD system with balancer, A/C clutch, idlers, tensioner, and supercharger hub
- Modified VMP Predator fuel rails for 2021+ F-150 applications
- Heat exchanger and Bosch intercooler pump included
- 55 lb/hr fuel injectors included
- Ford Performance spark plugs included
- MAP sensor and extension harness included
- 3.5-inch supercharger pulley included
- Approximately 10-11 psi of boost with the supplied pulley, depending on climate conditions
- SP Machining reported 588 wheel horsepower and 493 lb-ft of torque on 93 octane
- SP Machining reported 652 wheel horsepower and 520 lb-ft of torque on E85 with appropriate fuel system upgrades
- Optional OZ forced induction tuning available through HP Tuners
- Advertised $100 savings when adding an OZ forced induction tune
Kit Includes
- Billet aluminum Predator supercharger intake adapters
- Intake adapter mounting hardware and O-rings
- 6-rib FEAD system including:
- Balancer
- A/C clutch
- Idlers
- Tensioner
- Supercharger hub
- VMP Predator fuel rails modified for 2021+ Ford F-150 fitment
- Heat exchanger
- Bosch intercooler pump
- 55 lb/hr fuel injectors
- Ford Performance spark plugs
- MAP sensor and extension harness
- 3.5-inch supercharger pulley
Fitment
- 2021 Ford F-150 5.0L V8
- 2022 Ford F-150 5.0L V8
- 2023 Ford F-150 5.0L V8
- 2024 Ford F-150 5.0L V8
- 2025 Ford F-150 5.0L V8
- 2026 Ford F-150 5.0L V8
Important Fitment and Installation Notes
Supercharger Compatibility: Designed for Predator supercharger head units from the Ford Mustang Shelby GT500 and Ford F-150 Raptor R. The supercharger head unit itself is not listed among the included components.
Fuel System Limitations: SP Machining specifies 91-octane, 93-octane, and E30 fuel compatibility for this combination without additional fuel system upgrades. E85 operation requires fuel system upgrades.
E30 Performance: SP Machining states that similar power to its E85 results can be achieved on E30 without fuel system upgrades.
Fuel Pump Booster: SP Machining has announced plans for a wide-open-throttle (WOT) activated fuel pump booster for applications using smaller supercharger pulleys or E85. Confirm availability before ordering.
Boost Pressure: The included 3.5-inch pulley is reported to produce approximately 10-11 psi of boost, depending on climate conditions.
Tuning Compatibility: OZ forced induction tuning is offered through HP Tuners only. SCT devices are not supported for OZ forced induction tuning.
Professional Installation: SP Machining recommends professional installation.
Vehicle Compatibility: Intended for 2021+ Ford F-150 trucks equipped with the Gen 4 5.0L Coyote engine. Verify compatibility with the intended Predator supercharger head unit and supporting components before ordering.
