Fuel Injector Clinic 1440cc High Impedance Fuel Injector Set for Small Block Chevy Gen II Engines (IS300-1440H)
Give your Small Block Chevy Gen II engine the fueling capacity needed for serious horsepower with the Fuel Injector Clinic IS300-1440H High Impedance Fuel Injector Set. This complete set of eight injectors flows 1440cc/min (140 lb/hr) at 43.5 PSI (3 Bar) and an impressive 1700cc/min (160 lb/hr) at the factory 58 PSI (4 Bar) fuel pressure. Positioned between Fuel Injector Clinic's proven 1200cc and 1650cc injectors, the IS300-1440H delivers the ideal balance of excellent street manners, exceptional drivability, and the fuel volume required for high-horsepower gasoline and E85-powered combinations.
Built using the latest high impedance injector technology, the IS300-1440H features exceptional linearity, outstanding short pulse width repeatability, and Fuel Injector Clinic's proprietary Data Match Technology. Every injector is individually serial numbered and dynamically matched, with a detailed Data Match Sheet included to provide injector-specific flow and latency values for precise ECU calibration. This injector set includes PGTUSC8 injector pigtails, while optional PADPUtoJ8 Plug and Play adapters are available separately if you prefer an installation without cutting or soldering.
The 1440cc high impedance injector is compatible with virtually every popular performance fuel thanks to its stainless alloy valve construction. It is fully compatible with pump gasoline, E85, Q16, VP Import, FTW, MTBE oxygenated race fuels, and other racing fuels while maintaining excellent idle quality in street-driven vehicles. As with every Fuel Injector Clinic performance injector, these are brand-new injectors instead of remanufactured cores, providing exceptional reliability and long-term consistency.
Quick Specs
- Part Number: IS300-1440H
- Application: Small Block Chevy Gen II engines
- Injector Quantity: 8
- Injector Flow Rate: 1440cc/min (140 lb/hr) at 43.5 PSI (3 Bar)
- Injector Flow Rate: 1700cc/min (160 lb/hr) at OE 58 PSI (4 Bar)
- Injector Type: High impedance (saturated)
- Includes PGTUSC8 injector pigtails
- Optional PADPUtoJ8 Plug and Play adapters available
- Fuel Injector Clinic Data Match Technology
- Each injector individually serial numbered
- Detailed Data Match Sheet included
- Flow tested at 43.5 PSI (3 Bar)
- Tested using CF-16B calibration fluid at 90 degrees Fahrenheit
- Compatible with pump gasoline, E85, Q16, VP Import, FTW, and other MTBE oxygenated race fuels
- Stainless alloy valve construction
- Application-specific O-rings included
- Lifetime warranty against manufacturing defects
Features
- Designed specifically for Small Block Chevy Gen II engine applications
- Flows 1440cc/min (140 lb/hr) at 43.5 PSI and 1700cc/min (160 lb/hr) at OE 58 PSI fuel pressure
- Ideal injector size between Fuel Injector Clinic's 1200cc and 1650cc injector offerings
- Latest high impedance injector technology delivers excellent idle quality and drivability
- Outstanding linearity and superior short pulse width control for easier tuning
- Fuel Injector Clinic Data Match Technology ensures exceptional injector-to-injector consistency
- Each injector is individually serial numbered with detailed calibration data
- Includes PGTUSC8 injector pigtails for connector conversion
- Optional PADPUtoJ8 Plug and Play adapters available for installation without cutting or soldering
- Compatible with pump gasoline, E85, Q16, VP Import, FTW, and other MTBE oxygenated race fuels
- Stainless alloy valve construction provides outstanding durability and fuel compatibility
- Brand-new injectors eliminate the risks associated with remanufactured core injectors
- Application-specific O-rings included for proper installation
- Backed by Fuel Injector Clinic's lifetime warranty against manufacturing defects
Fitment
- Small Block Chevy Gen II engine applications requiring a set of eight high impedance fuel injectors
- Compatible with factory-style and compatible aftermarket fuel systems designed for this injector configuration
Installation and Connector Information
This injector set requires changing the injector connectors on your engine wiring harness. The included PGTUSC8 pigtails can be soldered onto the factory harness, or optional PADPUtoJ8 Plug and Play adapters can be purchased separately for installation without cutting or soldering.
Fuel Injector Clinic specifies this connector conversion because it uses brand-new, unused injectors instead of remanufactured or core-program injectors, providing greater reliability, consistency, and long-term performance.
FAQs
Can these injectors be used with E85 and race fuels?
Yes. Thanks to their stainless alloy valve construction, the IS300-1440H is compatible with pump gasoline, E85, Q16, VP Import, FTW, MTBE oxygenated race fuels, and other popular performance fuels while maintaining excellent idle quality and drivability.
Do these injectors require wiring modifications?
Yes. The included PGTUSC8 pigtails are designed for wiring harness conversion. If you would rather not modify your factory wiring, optional PADPUtoJ8 Plug and Play adapters are available separately.
Why Buy From Beefcake Racing?
Beefcake Racing proudly offers genuine Fuel Injector Clinic fuel injectors backed by competitive pricing, fast shipping, and knowledgeable technical support. Whether you're building a naturally aspirated Small Block Chevy, a boosted street machine, or a dedicated race car, our experienced team can help you select the ideal injectors and supporting fuel system components for your combination.
Need help selecting the right injector size for your build?
Email: sales@beefcakeracing.com
Phone: 1-855-827-7223
