Fuel Injector Clinic 775cc High Impedance Fuel Injector Set for Small Block Chevy Gen II Engines (IS300-0775H)
Support your high-performance Small Block Chevy Gen II build with the Fuel Injector Clinic IS300-0775H High Impedance Fuel Injector Set. This complete set of eight injectors flows 775cc/min (74 lb/hr) at 43.5 PSI (3 Bar) and 900cc/min (85 lb/hr) at the factory-style 58 PSI (4 Bar) fuel pressure. Utilizing the latest injector technology, these injectors deliver outstanding linearity, exceptional short pulse width repeatability, and excellent drivability while providing the fuel capacity needed for naturally aspirated, supercharged, turbocharged, and E85-capable performance combinations.
The IS300-0775H injector set is precisely matched using Fuel Injector Clinic's proprietary Data Match Technology. Every injector is individually serial numbered and includes a comprehensive Data Match Sheet containing injector-specific flow and latency values for highly accurate ECU calibration. Plug and Play GM ECU calibration data is also available from Fuel Injector Clinic, making tuning easier on supported GM engine management systems.
This injector set includes PGTUSC8 injector connector pigtails for wiring harness conversion. If you prefer not to modify the factory wiring, optional PADPUtoJ8 Plug and Play adapters are available separately, allowing installation without cutting or soldering. Fuel Injector Clinic specifies this connector arrangement because it uses brand-new, unused injectors instead of remanufactured or core-program injectors, providing exceptional reliability and consistent long-term performance.
Quick Specs
- Part Number: IS300-0775H
- Application: Small Block Chevy Gen II engines
- Injector Quantity: 8
- Injector Flow Rate: 775cc/min (74 lb/hr) at 43.5 PSI (3 Bar)
- Injector Flow Rate: 900cc/min (85 lb/hr) at OE 58 PSI (4 Bar)
- Injector Type: High impedance (saturated)
- Includes PGTUSC8 injector pigtails
- Optional PADPUtoJ8 Plug and Play adapters available
- Plug and Play GM ECU calibration data available
- Fuel Injector Clinic Data Match Technology
- Each injector individually serial numbered
- Detailed Data Match Sheet included
- Flow tested at 43.5 PSI (3 Bar)
- Tested using CF-16B calibration fluid at 90 degrees Fahrenheit
- Application-specific O-rings included
- Lifetime warranty against manufacturing defects
Features
- Designed specifically for Small Block Chevy Gen II engine applications
- Flows 775cc/min (74 lb/hr) at 43.5 PSI and 900cc/min (85 lb/hr) at OE 58 PSI fuel pressure
- Latest high impedance injector technology delivers precise and consistent fuel delivery
- Excellent linearity and superior short pulse width repeatability
- Fuel Injector Clinic Data Match Technology provides exceptional injector-to-injector consistency
- Each injector is individually serial numbered with an included Data Match Sheet
- Plug and Play GM ECU calibration data available for supported applications
- Includes PGTUSC8 wiring pigtails for connector conversion
- Optional PADPUtoJ8 adapters allow installation without cutting or soldering
- Brand-new injectors eliminate the concerns associated with remanufactured core injectors
- Application-specific O-rings included for proper installation
- Excellent idle quality, drivability, and tuning characteristics
- Backed by Fuel Injector Clinic's lifetime warranty against manufacturing defects
Fitment
- Small Block Chevy Gen II engine applications requiring a set of eight high impedance fuel injectors
- Compatible with factory-style and compatible aftermarket fuel systems designed for this injector configuration
Installation and Connector Information
This injector set requires changing the injector connectors on your engine wiring harness. The included PGTUSC8 pigtails can be soldered onto the factory harness, or optional PADPUtoJ8 Plug and Play adapters can be purchased separately to provide a true plug-and-play installation without cutting or soldering.
Fuel Injector Clinic specifies this connector conversion because it uses brand-new, unused injectors rather than remanufactured or core-program injectors, helping ensure maximum reliability, consistency, and long service life.
FAQs
Do these injectors require modifying the factory wiring?
Yes. The included PGTUSC8 pigtails replace the factory injector connectors. If you prefer to leave the factory wiring untouched, optional PADPUtoJ8 Plug and Play adapters are available separately.
Is ECU calibration data available for these injectors?
Yes. Fuel Injector Clinic provides Plug and Play GM ECU calibration data for supported GM engine management systems, making tuning faster and more accurate.
