Fuel Injector Clinic 775cc Fuel Injector Set - High Z (is140-0775h) - Scion tC / xB / Toyota 1ZZ
Give your Scion or compatible Toyota build the fuel capacity it needs without sacrificing the drivability you expect on the street. The Fuel Injector Clinic is140-0775h is a complete set of four 775cc saturated, high-impedance ball and seat injectors engineered for excellent linearity, repeatable short pulse width operation, and accurate fuel delivery across the operating range. For modified street cars and performance builds that have outgrown the factory fuel system, these injectors provide a proven step up in fueling capability while maintaining the precise control needed for a clean, predictable tune.
Fuel Injector Clinic uses its proprietary Data Match Technology to precisely match the injectors as a set. Each injector is individually serial numbered, and the included Data Match Sheet provides detailed flow matching and latency information to support accurate ECU calibration. The injectors are flow tested and rated at 43.5 PSI (3 Bar) with fuel at 90 degrees F using CF-16B calibration fluid. PGTUSC4 solder-in pigtails are included, or optional PADPUtoT4 plug-and-play adapters can be added for installation without cutting or soldering the applicable factory harness.
Specifications
- Manufacturer: Fuel Injector Clinic
- Part Number: is140-0775h
- Flow Rate: 775cc/min
- Injector Quantity: 4
- Injector Type: Saturated / high impedance ball and seat
- Impedance: High-Z / high impedance
- Matching Technology: Fuel Injector Clinic Data Match Technology
- Flow Test Pressure: 43.5 PSI (3 Bar)
- Flow Test Fuel Temperature: 90 degrees F
- Calibration Fluid: CF-16B
- Pigtails: PGTUSC4 included
- Optional Plug-and-Play Adapters: PADPUtoT4
- O-Rings: Included as required for the listed factory application
- Warranty: Lifetime warranty against failure caused by defects in original manufacture
Features
- Complete matched set of four 775cc/min performance fuel injectors
- Saturated, high-impedance ball and seat injector design
- Excellent linearity for predictable fuel delivery
- Strong short pulse width repeatability for improved low-load control
- Precisely matched using Fuel Injector Clinic Data Match Technology
- Each injector is individually serial numbered
- Detailed Data Match Sheet includes flow matching and latency information
- Flow tested and rated at 43.5 PSI (3 Bar) and 90 degrees F using CF-16B calibration fluid
- Designed for accurate tuning and strong drivability
- PGTUSC4 solder-in pigtails included
- Optional PADPUtoT4 plug-and-play adapters eliminate the need to cut or solder the applicable factory harness
- Configured with the O-rings required for the listed factory application
- Uses brand-new, unused injectors rather than remanufactured or core-program units
- Lifetime warranty against failure caused by defects in original manufacture
Data Match Technology
Injector flow rate is only part of the equation when building a fuel system that is easy to tune. Consistency between injectors is critical, especially when precise fuel delivery is expected from idle through wide-open throttle. Fuel Injector Clinic's Data Match Technology is designed to closely match the operating characteristics of every injector in the set rather than relying solely on a single static flow measurement.
Each is140-0775h injector is individually serial numbered, and the set includes a detailed Data Match Sheet with flow matching and latency information. This data gives your tuner valuable information for establishing accurate injector calibration and helps deliver consistent fueling across all four cylinders.
Designed for Performance and Drivability
The 775cc high-impedance injectors combine increased fuel capacity with the linearity and short pulse width repeatability required for a well-mannered performance combination. Tight manufacturing tolerances and precise matching help make these injectors easier to tune while supporting smooth, consistent operation during the low pulse width conditions encountered during idle and part-throttle driving.
Fuel Injector Clinic also uses brand-new, unused injectors for its performance applications rather than relying on remanufactured injectors or core programs. That approach eliminates the additional uncertainty associated with starting with previously used injector components.
Wiring and Installation
The is140-0775h set includes PGTUSC4 solder-in pigtails for converting the applicable factory injector connectors. The original plugs can be removed and the supplied pigtails soldered into the vehicle's wiring harness. For an installation that does not require cutting or soldering the factory harness, optional PADPUtoT4 plug-and-play adapters can be added.
Fuel Injector Clinic supplies the injectors with the O-rings required for the listed factory application. Vehicles using aftermarket fuel rails or other non-standard fuel-system configurations should be verified before ordering to ensure the correct injector setup is selected.
Fitment
- 2005 Scion tC
- 2006 Scion tC
- 2007 Scion tC
- 2008 Scion tC
- 2009 Scion tC
- 2010 Scion tC
- 2011 Scion tC
- 2012 Scion tC
- 2013 Scion tC
- 2014 Scion tC
- 2015 Scion tC
- 2016 Scion tC
- 2008 Scion xB
- 2009 Scion xB
- 2010 Scion xB
- 2011 Scion xB
- 2012 Scion xB
- 2013 Scion xB
- 2014 Scion xB
- 2015 Scion xB
- Select Toyota applications utilizing the 1ZZ engine
FAQs
What is included with the Fuel Injector Clinic is140-0775h injector set?
The set includes four 775cc High-Z ball and seat fuel injectors, PGTUSC4 solder-in pigtails, the required O-rings for the listed factory application, and injector matching data. Optional PADPUtoT4 plug-and-play adapters are available separately.
Do the FIC is140-0775h injectors require a wiring modification?
Yes, when using the included PGTUSC4 pigtails, the applicable factory injector connectors must be replaced by soldering in the supplied pigtails. Optional PADPUtoT4 plug-and-play adapters provide a no-cut, no-solder alternative for connecting the injectors to the applicable factory harness.
