Fuel Injector Clinic Eight Cylinder 1000cc SHORT Custom Injector Set - 38mm Height - 14mm Top O-Ring - 16mm Bottom O-Ring (1000-38-14-16-8)
Bring serious fueling capability to a space-conscious 8-cylinder build with the Fuel Injector Clinic 1000cc SHORT Custom Injector Set. This complete set of eight 1000cc high-performance injectors uses a compact 38mm body with a 14mm top O-ring diameter and 16mm bottom O-ring diameter, making it a purpose-built option for top-feed applications requiring this short injector configuration. Fuel Injector Clinic can adapt its injectors to match top-feed applications, giving performance builders the flexibility to select an injector configuration that works with the fuel system instead of compromising the build around the wrong dimensions.
These 1000cc SHORT injectors are data matched for consistent performance and are E85 compatible, making them a strong choice for performance-oriented street and race fuel systems requiring this flow rate and physical configuration. Fuel Injector Clinic's performance injector program is built around precise injector matching to give tuners the consistency they need when calibrating demanding combinations. Each injector is also backed by Fuel Injector Clinic's lifetime warranty for long-term confidence in your fuel system.
Specifications
- Manufacturer: Fuel Injector Clinic
- Product Code: 1000-38-14-16-8
- FIC Part Number: ISC-1000H-SHORT-8
- Injector Flow Rate: 1000cc/min
- Engine Configuration: 8-cylinder
- Injector Quantity: 8
- Injector Style: Top-feed
- Injector Height: 38mm short height
- Top O-Ring Diameter: 14mm
- Bottom O-Ring Diameter: 16mm
- Matching: Data matched
- Fuel Compatibility: E85 compatible
- Warranty: Lifetime warranty
Features
- Complete set of eight 1000cc high-performance fuel injectors
- Compact 38mm SHORT configuration for applications requiring a shorter injector body
- 14mm top O-ring and 16mm bottom O-ring configuration
- Designed for custom top-feed fuel injector applications
- Data matched for consistent injector performance
- E85 compatible for performance builds running ethanol-based fuel
- 1000cc/min flow capacity for performance-oriented 8-cylinder fuel systems
- Custom configuration provides flexibility when building or upgrading an aftermarket fuel system
- Purpose-built option for applications requiring a compact 38mm injector configuration
- Backed by Fuel Injector Clinic's lifetime warranty
Fitment
Custom 8-cylinder top-feed applications requiring 1000cc injectors with a 38mm short height, 14mm top O-ring diameter, and 16mm bottom O-ring diameter.
This is a custom injector configuration and does not have vehicle-specific fitment. Verify your fuel rail, intake, injector height, and upper and lower O-ring requirements before ordering, particularly when working with aftermarket or otherwise non-standard fuel system components.
FAQs
Are these Fuel Injector Clinic 1000cc SHORT injectors E85 compatible?
Yes. Fuel Injector Clinic specifies the 1000cc SHORT high-performance injectors as E85 compatible, making this set an option for E85-fueled performance builds when its 1000cc flow rate and physical dimensions meet the requirements of the fuel system.
How do I know if this 1000cc SHORT injector configuration is right for my application?
Verify that your top-feed fuel system requires a 38mm short-height injector with a 14mm top O-ring diameter and 16mm bottom O-ring diameter. Because this is a custom injector set rather than a vehicle-specific application, confirming the injector dimensions against your fuel rail and intake setup before ordering is essential.
