Fuel Injector Clinic Eight Cylinder 365cc Custom Injector Set (0365-64-14-15-8) - 64mm Height, 14mm Top, 15mm Bottom
Build your custom eight-cylinder fuel system around precise, consistent fuel delivery with the Fuel Injector Clinic 365cc Custom Injector Set. This 0365-64-14-15-8 configuration combines a 365cc flow rate with a 64mm injector height, 14mm top O-ring diameter, and 15mm bottom O-ring diameter. Each eight-injector set is precisely flow matched to within 1 percent, helping deliver consistent fueling from cylinder to cylinder while giving tuners a dependable foundation for accurate calibration and excellent drivability.
Fuel Injector Clinic individually numbers every injector in the set and provides a detailed flow sheet showing the results for each injector. These high-performance injectors are flow tested and rated at 43.5 psi (3 Bar) with fuel maintained at 90 degrees F using CF-16B calibration fluid. Superior short pulse width control and tight manufacturing tolerances help make these injectors easy to tune while maintaining smooth, predictable fuel delivery. Custom injector sets include solder-in pigtails and the O-rings required for the selected configuration. Every injector is backed by Fuel Injector Clinic's lifetime warranty against failure caused by defects in original manufacture.
Specifications
- Manufacturer: Fuel Injector Clinic
- Manufacturer Part Number: ISC-0365H-8
- Product Code: 0365-64-14-15-8
- Flow Rate: 365cc
- Engine Configuration: Eight-cylinder
- Injector Quantity: 8
- Injector Height: 64mm
- Top O-Ring Diameter: 14mm
- Bottom O-Ring Diameter: 15mm
- Flow Matching: Precisely matched to within 1 percent
- Test Pressure: 43.5 psi (3 Bar)
- Test Fuel Temperature: 90 degrees F
- Calibration Fluid: CF-16B
- Included Wiring: Solder-in pigtails
- Warranty: Lifetime warranty against failure caused by defects in original manufacture
Features
- Complete custom injector set for an eight-cylinder engine
- Eight 365cc high-performance fuel injectors
- Precisely flow matched to within 1 percent for consistent cylinder-to-cylinder fuel delivery
- Each injector is individually numbered for identification
- Detailed flow sheet provides individual injector results
- Flow tested and rated at 43.5 psi (3 Bar)
- Testing performed at a controlled 90 degrees F fuel temperature using CF-16B calibration fluid
- Superior short pulse width control supports precise injector operation
- Tight manufacturing tolerances help simplify tuning and promote excellent drivability
- 64mm injector height with 14mm top and 15mm bottom O-ring diameters
- Includes the O-rings required for the selected injector configuration
- Solder-in pigtails included with the custom injector set
- Covered by Fuel Injector Clinic's lifetime warranty against failure caused by defects in original manufacture
Fitment
- Universal/custom eight-cylinder applications requiring 365cc injectors
- 64mm injector height
- 14mm top O-ring diameter
- 15mm bottom O-ring diameter
This is a custom injector configuration and does not have vehicle-specific fitment. Compatibility depends on the fuel rail, intake manifold, injector bore dimensions, and overall fuel-system configuration. For aftermarket or unusual setups, confirm the required injector dimensions before ordering to ensure proper fitment.
FAQs
How are the Fuel Injector Clinic 365cc injectors matched and tested?
Fuel Injector Clinic precisely flow matches its high-performance injector sets to within 1 percent. Each injector is individually numbered, with its results provided on the detailed flow sheet included with the set. The injectors are flow tested and rated at 43.5 psi (3 Bar) at a fuel temperature of 90 degrees F using CF-16B calibration fluid.
What configuration is Fuel Injector Clinic Product Code 0365-64-14-15-8?
Product Code 0365-64-14-15-8 is a custom set of eight 365cc injectors configured with a 64mm injector height, 14mm top O-ring diameter, and 15mm bottom O-ring diameter. Solder-in pigtails are also included. Confirm these dimensions against your specific fuel-system requirements before ordering.
Why Buy from Beefcake Racing?
Beefcake Racing is your source for Fuel Injector Clinic injectors and performance fuel-system components. With custom injector applications, choosing the correct flow rate, injector height, and O-ring dimensions is essential for building the right combination. If you have questions about Fuel Injector Clinic Product Code 0365-64-14-15-8 or need help confirming the correct injector configuration for your build, call Beefcake Racing at 1-855-827-7223 or email sales@beefcakeracing.com.
