Fuel Injector Clinic Eight Cylinder 365cc Custom Injector Set - 53mm Height - 14mm Top O-Ring - 15mm Bottom O-Ring (0365-53-14-15-8)
Build your custom 8-cylinder fuel system around precise, consistent fuel delivery with this Fuel Injector Clinic 365cc Custom Injector Set. Configured with a 53mm height, 14mm top O-ring diameter, and 15mm bottom O-ring diameter, this complete eight-injector set is designed for applications requiring these specific injector dimensions. Fuel Injector Clinic combines precise flow matching, superior short pulse width control, and tight manufacturing tolerances to deliver predictable fueling, straightforward tuning, and excellent drivability. Solder-in pigtails are included for custom installation requirements.
Fuel Injector Clinic precisely flow matches each injector set to within 1 percent. Every injector is individually numbered, with its results documented on the detailed flow sheet supplied with the set. The injectors are flow tested and rated at 43.5 psi (3 Bar) at a fuel temperature of 90 degrees F using CF-16B calibration fluid. O-rings are included for the specified injector configuration, and every injector is backed by Fuel Injector Clinic's lifetime warranty against failure caused by defects in original manufacture.
Specifications
- Manufacturer: Fuel Injector Clinic
- Product Code: 0365-53-14-15-8
- FIC Part Number: ISC-0365H-8
- Injector Flow Rate: 365cc/min
- Engine Configuration: 8-cylinder
- Injector Quantity: 8
- Injector Height: 53mm
- Top O-Ring Diameter: 14mm
- Bottom O-Ring Diameter: 15mm
- Flow Matching: Precisely matched to within 1 percent
- Test Pressure: 43.5 psi (3 Bar)
- Test Fuel Temperature: 90 degrees F
- Calibration Fluid: CF-16B
- Included: Solder-in pigtails and O-rings for the specified configuration
- Warranty: Lifetime warranty against failure caused by defects in original manufacture
Features
- Complete matched set of eight 365cc high-performance fuel injectors
- Precisely flow matched to within 1 percent for consistent injector-to-injector fuel delivery
- Each injector is individually numbered with results provided on the included detailed flow sheet
- Superior short pulse width control supports precise fueling and excellent drivability
- Tight manufacturing tolerances help provide predictable, tuner-friendly performance
- Flow tested and rated at 43.5 psi (3 Bar) at 90 degrees F fuel temperature
- Tested using CF-16B calibration fluid
- 53mm injector height for custom fuel system applications requiring this dimension
- 14mm top O-ring and 15mm bottom O-ring configuration
- Solder-in pigtails included for custom installation requirements
- O-rings included for the specified injector configuration
- Backed by Fuel Injector Clinic's lifetime warranty against qualifying manufacturing defects
Fitment
Custom 8-cylinder applications requiring 365cc injectors with a 53mm height, 14mm top O-ring diameter, and 15mm bottom O-ring diameter.
This custom injector set does not have vehicle-specific fitment. For aftermarket fuel rails, intake systems, or other non-standard fuel system configurations, verify the required injector height and O-ring dimensions before ordering to ensure proper fitment.
FAQs
Are these Fuel Injector Clinic 365cc injectors flow matched?
Yes. Fuel Injector Clinic precisely flow matches the injectors in this eight-injector set to within 1 percent. Each injector is individually numbered, and its results are documented on the detailed flow sheet included with the set.
How do I know if this 53mm, 14mm top, and 15mm bottom configuration is right for my application?
Confirm that your fuel rail and intake setup require a 53mm injector height, 14mm top O-ring diameter, and 15mm bottom O-ring diameter. Because this is a custom injector set rather than a vehicle-specific application, verify these dimensions before ordering, especially when using aftermarket or non-standard fuel system components.
Why Buy Fuel Injector Clinic Injectors From Beefcake Racing?
Choosing the correct injector configuration is critical to getting the fit and fuel delivery your performance combination requires. Beefcake Racing can help you select the right Fuel Injector Clinic injectors and supporting fuel system components for your build. Have questions about this 365cc custom injector set or your fuel system setup? Call Beefcake Racing at 1-855-827-7223 or email sales@beefcakeracing.com.
