Fuel Injector Clinic Eight Cylinder 365cc Custom Injector Set - 53mm Height - 11mm Top O-Ring - 16mm Bottom O-Ring (0365-53-11-16-8)
Get the precise fuel delivery your custom 8-cylinder build demands with this Fuel Injector Clinic 365cc Custom Injector Set. Configured with a 53mm height, 11mm top O-ring diameter, and 16mm bottom O-ring diameter, this complete eight-injector set is built for applications requiring these specific dimensions. Fuel Injector Clinic combines precise flow matching, superior short pulse width control, and tight manufacturing tolerances to deliver consistent fueling, straightforward tuning, and excellent drivability. Solder-in pigtails are included for custom installation requirements.
Fuel Injector Clinic precisely flow matches each injector set to within 1 percent. Every injector is individually numbered, and its results are documented on the detailed flow sheet supplied with the set. The injectors are flow tested and rated at 43.5 psi (3 Bar) at a fuel temperature of 90 degrees F using CF-16B calibration fluid. The necessary O-rings are included for the specified configuration, and every injector is backed by Fuel Injector Clinic's lifetime warranty against failure caused by defects in original manufacture.
Specifications
- Manufacturer: Fuel Injector Clinic
- Product Code: 0365-53-11-16-8
- FIC Part Number: ISC-0365H-8
- Injector Flow Rate: 365cc/min
- Engine Configuration: 8-cylinder
- Injector Quantity: 8
- Injector Height: 53mm
- Top O-Ring Diameter: 11mm
- Bottom O-Ring Diameter: 16mm
- Flow Matching: Precisely matched to within 1 percent
- Test Pressure: 43.5 psi (3 Bar)
- Test Fuel Temperature: 90 degrees F
- Calibration Fluid: CF-16B
- Included: Solder-in pigtails and O-rings for the specified configuration
- Warranty: Lifetime warranty against failure caused by defects in original manufacture
Features
- Complete matched set of eight 365cc high-performance fuel injectors
- Precisely flow matched to within 1 percent for consistent injector-to-injector fuel delivery
- Each injector is individually numbered with results provided on the included detailed flow sheet
- Superior short pulse width control supports precise fueling and excellent drivability
- Tight manufacturing tolerances help provide predictable, tuner-friendly performance
- Flow tested and rated at 43.5 psi (3 Bar) at 90 degrees F fuel temperature
- Tested using CF-16B calibration fluid
- 53mm injector height for custom applications requiring this physical configuration
- 11mm top O-ring and 16mm bottom O-ring diameters
- Solder-in pigtails included for custom installation requirements
- O-rings included for the specified injector configuration
- Backed by Fuel Injector Clinic's lifetime warranty against qualifying manufacturing defects
Fitment
Custom 8-cylinder applications requiring 365cc injectors with a 53mm height, 11mm top O-ring diameter, and 16mm bottom O-ring diameter.
This is a custom injector configuration and does not have vehicle-specific fitment. For aftermarket fuel rails, intake systems, or other non-standard fuel system setups, verify the required injector height and O-ring dimensions before ordering to ensure proper fitment.
FAQs
Are these Fuel Injector Clinic 365cc injectors flow matched?
Yes. Fuel Injector Clinic precisely flow matches the injectors in this eight-injector set to within 1 percent. Each injector is individually numbered, and its results are provided on the detailed flow sheet included with the set.
How do I know if the 53mm, 11mm top, and 16mm bottom configuration is correct for my application?
Confirm that your fuel rail and intake setup require a 53mm injector height, 11mm top O-ring diameter, and 16mm bottom O-ring diameter. Because this is a custom injector configuration rather than a vehicle-specific application, verifying these dimensions before ordering is especially important when using aftermarket or non-standard fuel system components.
