DSE LS Engine Mount Kit - Hydroformed Subframe (060414DS) - 1970-1981 Camaro / Firebird
Build your second-generation F-Body around modern GM LS power with an engine mounting system engineered specifically for the Detroit Speed Hydroformed Subframe. Detroit Speed LS Engine Mount Kit 060414DS is designed for LS engine installations in 1970-1981 Chevrolet Camaro and Pontiac Firebird applications equipped with the DSE Hydroformed Subframe. Rather than adapting universal mounts to the chassis, this kit provides the application-specific components needed to integrate the LS engine with the Detroit Speed front suspension system.
The 060414DS package includes left- and right-hand engine mount adapter plates, left- and right-hand frame stands, two polyurethane engine mounts, and the required installation hardware. Current Detroit Speed subframe documentation specifies this mounting kit for LS1, LS2, and LS3 engines and positions the engine 1.5 inches rearward of the stock location. Detroit Speed also lists multiple compatible oil-pan configurations and specifically requires 060414DS when using DSE 061001DS LS headers, making this mount kit a critical piece of a properly planned second-gen Camaro or Firebird LS conversion.
Specifications
- Manufacturer: Detroit Speed
- Part Number: 060414DS
- Product Type: LS Engine Mount Kit
- Vehicle Application: 1970-1981 Chevrolet Camaro / Pontiac Firebird
- Subframe Compatibility: Detroit Speed Hydroformed Subframe
- Documented Engine Applications: GM LS1, LS2 and LS3
- Engine Position: 1.5 inches rearward of stock location
- Engine Mount Adapter Plates: Left and right included
- Frame Stands: Left and right included
- Engine Mounts: Two included
- Engine Mount Material: Polyurethane
- Installation Hardware: Included
- DSE Header Compatibility: DSE 061001DS headers require 060414DS
Features
- Purpose-built LS engine mounting solution for the Detroit Speed Hydroformed Subframe
- Designed for 1970-1981 Chevrolet Camaro and Pontiac Firebird applications
- Current Detroit Speed documentation specifies the kit for LS1, LS2, and LS3 engine installations
- Positions the LS engine 1.5 inches rearward of the stock engine location
- Includes left- and right-hand engine mount adapter plates
- Includes left- and right-hand frame stands
- Includes two polyurethane engine mounts
- Includes the required mounting hardware
- Designed as an integrated mounting solution rather than relying on universal engine mounts and fabricated brackets
- Required engine mount kit for Detroit Speed 061001DS LS headers in this DSE Hydroformed Subframe application
- Detroit Speed documentation provides multiple compatible oil-pan options to accommodate different LS build configurations
Fitment
- 1970 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1970 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1971 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1971 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1972 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1972 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1973 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1973 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1974 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1974 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1975 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1975 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1976 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1976 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1977 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1977 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1978 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1978 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1979 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1979 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1980 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1980 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
- 1981 Chevrolet Camaro with DSE Hydroformed Subframe and compatible GM LS engine
- 1981 Pontiac Firebird with DSE Hydroformed Subframe and compatible GM LS engine
Fitment Note: Detroit Speed 060414DS is designed for LS engine installation in 1970-1981 Camaro and Firebird models equipped with the Detroit Speed Hydroformed Subframe. Current Detroit Speed documentation specifies 060414DS for LS1, LS2, and LS3 engines and locates the engine 1.5 inches rearward of the stock position. Listed oil-pan options include the LS2/LS3 Corvette GM 12624617, fourth-generation F-Body GM 12628771, Champ LS1000, Mast Motorsports 401-111, and Holley 302-2, 302-3, or 302-5. Detroit Speed notes that firewall or transmission tunnel modification may be necessary when using its engine mount kits. DSE 061001DS headers require engine mount kit 060414DS.
FAQs
What engines does Detroit Speed 060414DS support?
Current Detroit Speed engine-fitment documentation specifies 060414DS for LS1, LS2, and LS3 engine installations in the compatible 1970-1981 Camaro and Firebird Hydroformed Subframe application.
What comes with Detroit Speed 060414DS?
The dedicated Detroit Speed installation instructions identify left- and right-hand engine mount adapter plates, left- and right-hand frame stands, two polyurethane engine mounts, and the required installation hardware.
Where does 060414DS position the LS engine?
Detroit Speed specifies that the LS engine is positioned 1.5 inches rearward of the stock engine location. Detroit Speed also notes that firewall or transmission tunnel modification may be required when using its engine mount kits.
