DSE X-Gen 595 Front Suspension Module - Without Springs / Shocks (032061DS)
Build modern Detroit Speed suspension performance into a custom chassis with the X-Gen 595 Front Suspension Module 032061DS. Rather than adapting a suspension designed around a specific production vehicle, the X-Gen platform gives fabricators and builders a complete 59.5-inch track-width front suspension module engineered to be integrated into a custom application through its 2 x 4-inch frame rail sections. The architecture is based on the same proven suspension systems used in Detroit Speed's bolt-in front frames, giving custom builds access to Detroit Speed suspension geometry, structural design, steering, and chassis engineering in a package built for both street and track performance.
Part number 032061DS is configured with a GM 5 x 4.75-inch bolt pattern and is supplied without coilover shocks or springs, allowing the suspension's spring and shock package to be selected around the weight, intended use, and requirements of the vehicle being built. The module uses 2 x 4 x 0.120-inch wall frame rails measuring 25.25 inches long and provides 6 inches of total suspension travel. With its 59.5-inch track width, 34.25-inch outer-to-outer frame width, and maximum wheel backspacing of 6.125 inches, the X-Gen 595 gives serious builders a defined foundation for engineering a high-performance custom front suspension installation.
Specifications
- Manufacturer: Detroit Speed
- Part Number: 032061DS
- Product Type: X-Gen Front Suspension Module
- Series: X-Gen 595
- Application: Universal / Custom Fabrication
- Track Width: 59.5 inches
- Bolt Pattern: GM 5 x 4.75 inches
- Frame Rail Dimensions: 2 x 4 x 0.120-inch wall
- Frame Rail Length: 25.25 inches
- Outer-to-Outer Frame Width: 34.25 inches
- Distance from Rear of Frame Rail to Suspension Axis: 13.188 inches
- Total Suspension Travel: 6 inches
- Nominal Ride Height: 1.9 inches
- Maximum Wheel Backspacing: 6.125 inches
- Shock Type: Not Included
- Coilover Shocks: Not Included
- Coilover Springs: Not Included
Features
- Universal X-Gen suspension architecture allows Detroit Speed front suspension technology to be integrated into custom vehicle applications
- 59.5-inch track width provides a defined foundation for custom chassis and fabrication projects
- Uses the same suspension system architecture found in Detroit Speed bolt-in front frames
- Detroit Speed suspension geometry is engineered for high-performance ride and handling
- 2 x 4 x 0.120-inch wall frame rail sections are designed to be integrated into the vehicle chassis
- 25.25-inch frame rail length provides a substantial foundation for chassis integration
- Provides 6 inches of total suspension travel
- GM 5 x 4.75-inch bolt pattern
- Maximum wheel backspacing of 6.125 inches
- 34.25-inch outer-to-outer frame width
- Supplied without coilover shocks or springs for application-specific suspension setup
- Allows shock and spring selection to be tailored to the vehicle and intended use
- Engineered for high-performance street and track applications
Fitment Notes
- This is a universal suspension module intended for custom fabrication and is not a direct bolt-in vehicle-specific suspension kit
- The 2 x 4-inch frame rail sections must be integrated into the vehicle chassis
- Professional fabrication and chassis setup are recommended
- Coilover shocks are not included
- Coilover springs are not included
- Spring rates and shock specifications must be selected according to the vehicle's weight, configuration, intended use, and suspension requirements
- Wheel selection must account for the 59.5-inch track width, GM 5 x 4.75-inch bolt pattern, and maximum 6.125-inch wheel backspacing
- The X-Gen suspension module must ship via freight
FAQs
What is the DSE X-Gen 595 032061DS designed for?
The X-Gen 595 is designed to integrate Detroit Speed front suspension technology into custom vehicle and chassis applications. Its frame rail sections provide the foundation for fabricating the module into the vehicle rather than relying on a vehicle-specific bolt-in mounting arrangement.
What is the track width of DSE 032061DS?
Detroit Speed specifies a 59.5-inch track width for part number 032061DS.
Are shocks and springs included with 032061DS?
No. This version of the X-Gen 595 is specifically supplied without coilover shocks or springs, allowing those components to be selected according to the requirements of the vehicle and build.
What bolt pattern does DSE 032061DS use?
Part number 032061DS uses a GM 5 x 4.75-inch bolt pattern.
Is the X-Gen 595 a bolt-in suspension kit?
No. The X-Gen is a universal suspension module intended to be integrated into a custom application through its 2 x 4-inch frame rail sections. Fabrication is required for installation.
How much suspension travel does the X-Gen 595 provide?
Detroit Speed specifies 6 inches of total suspension travel for the 032061DS X-Gen 595 module.
Why Buy Detroit Speed from Beefcake Racing?
Beefcake Racing is your source for Detroit Speed suspension, steering, chassis, and pro-touring components for serious performance builds. A universal suspension module requires careful planning around chassis dimensions, wheel fitment, spring rates, shocks, steering, and the overall vehicle configuration, and our team can help you select the right components for your project. Questions about DSE 032061DS or your custom suspension build? Email sales@beefcakeracing.com or call 1-855-827-7223.
