Apex VS-5 17x8.5 Flow Formed Wheel - 5x114.3 BP / ET23 / 60.1mm CB - Hyper Black (VS51785ET23-51143-601-NHBK)
The Apex VS-5 redefines what enthusiasts can expect from a flow-formed wheel. Finished in stunning Hyper Black, this 17x8.5 wheel combines an iconic five-spoke design with advanced engineering techniques that deliver a strength-to-weight ratio normally associated with forged wheels. Weighing only approximately 2 to 2.5 pounds more than its forged counterpart, the VS-5 represents the final step before moving to a fully forged setup.
Built as part of Apex's Evolution Line, the VS-5 utilizes advanced flow-forming technology, side-milled spokes, and extensive Finite Element Analysis to maximize strength and stiffness while minimizing unnecessary weight. Deep concave profiles, exceptional brake clearance, and a reinforced inner lip make this wheel equally capable on the street or at the track.
Features
- Advanced flow-formed aluminum construction
- Hyper Black finish
- Iconic five-spoke design
- Side-milled spokes for reduced weight and improved aesthetics
- Reinforced inner lip for enhanced durability
- Ultra-concave face profiles maximize appearance and performance
- Large brake clearance with 0-degree draft barrel design
- Finite Element Analysis optimized structure
- Lightweight design with forged-inspired strength
- Compatible with oversized race lugs and impact sockets
- Multi-stage paint process over powder-coated base coat
- JWL compliant and engineered beyond minimum standards
- Hub-centric design minimizes the need for centering rings
- Gloss black Apex center cap included
- Compatible with OEM hardware and most wheel spacers
- Accepts OEM and aftermarket TPMS sensors
- Compatible with standard valve stems
Specifications
- Part Number: VS51785ET23-51143-601-NHBK
- Series: VS-5 Evolution Line
- Wheel Size: 17x8.5
- Bolt Pattern: 5x114.3 BP
- Offset: ET23
- Center Bore: 60.1mm
- Finish: Hyper Black
- Construction: Flow Formed Aluminum
- Center Cap Included: Yes
- TPMS Compatible: Yes
Engineered to Push Flow-Formed Performance Further
The VS-5 was designed to deliver exceptional performance without compromise. Side-milled spokes, deep concavity, and a reinforced inner lip work together to create a wheel that offers remarkable durability and low weight. Combined with extensive brake clearance and hub-centric construction, the VS-5 is ready for everything from spirited backroad driving to demanding track sessions.
Fitment
- Applications utilizing a 5x114.3 bolt pattern and 60.1mm center bore
- ET23 offset specification
- Verify brake, suspension, tire, and fender clearances before installation
FAQs
What makes the VS-5 different from conventional flow-formed wheels?
The VS-5 utilizes side-milled spokes, extensive FEA optimization, and a reinforced inner lip to achieve a strength-to-weight ratio approaching that of forged wheels while maintaining excellent value.
Will factory TPMS sensors work with these wheels?
Yes. The VS-5 accepts OEM and aftermarket TPMS sensors and supports standard valve stems for easy installation.
