Apex SM-8RS 17x9 Forged Wheel - 4x100 BP / ET45 / 54.1mm CB - Satin Bronze (SM8RS179ET45-4100-541-NSBZ)
The Apex SM-8RS brings true motorsport engineering to lightweight sports car applications with a forged eight-spoke design developed specifically around the demands of the Mazda ND MX-5 Miata platform. Part of Apex's Sprint Line, the SM-8RS delivers exceptional strength, low weight, and impressive stiffness for track enthusiasts and aggressive street drivers alike. Finished in Satin Bronze, this wheel offers race-inspired style backed by serious performance.
Manufactured from forged 6061-T6 aluminum using an immense 10,000-ton forging process, the SM-8RS boasts an outstanding 1,400-pound load rating. That's over 230 pounds stronger than required for JWL certification and roughly 185 pounds stronger than many aftermarket ND Miata wheel options. Extensive FEA optimization, I-beam spokes, and a reinforced Sprint spec inner lip help provide exceptional durability and stiffness without compromising weight.
Features
- Forged 6061-T6 aluminum construction
- Produced with a 10,000-ton forging process
- Designed specifically for ND MX-5 Miata applications
- Outstanding 1,400-pound load rating
- Over 230 pounds stronger than JWL requirements
- Approximately 185 pounds stronger than many aftermarket alternatives
- I-beam side-milled spokes reduce weight while maintaining rigidity
- Purpose-built motorsport blanks provide deeper spokes and increased strength
- FEA-optimized spoke geometry improves stiffness
- Sprint spec inner lip is 32% stronger than previous designs
- Independently tested beyond JWL standards
- Designed to clear OEM Brembo brakes and many aftermarket BBKs
- Paintless knurled bead seats improve tire retention
- Compatible with oversized race lugs and impact sockets
- Laser-engraved wheel specifications
- Hub-centric design minimizes the need for centering rings
- Gloss black Apex center cap included
- Supports OEM and aftermarket TPMS sensors
- Accepts standard valve stems
- Premium Satin Bronze finish
Specifications
- Part Number: SM8RS179ET45-4100-541-NSBZ
- Wheel Series: SM-8RS Sprint Line
- Wheel Size: 17x9
- Bolt Pattern: 4x100 BP
- Offset: ET45
- Center Bore: 54.1mm
- Finish: Satin Bronze
- Material: Forged 6061-T6 Aluminum
- Load Rating: 1,400 lbs
Built for Serious Driving
The SM-8RS was engineered to provide exceptional track durability without sacrificing responsiveness. Through extensive computer simulations and independent laboratory testing, Apex created a wheel capable of handling high grip levels, hard braking, and repeated track abuse while maintaining the lightweight characteristics enthusiasts demand.
Fitment
- Applications utilizing a 4x100 bolt pattern and 54.1mm center bore
- ET45 offset specification
- Verify brake, tire, suspension, and fender clearance before installation
FAQs
Will the SM-8RS clear factory Brembo brakes?
Yes. The 17x9 and 17x10 SM-8RS fitments were engineered specifically to provide clearance for factory Brembo packages and many aftermarket big brake kits.
Can factory TPMS sensors be reused?
Yes. The SM-8RS accepts OEM and aftermarket TPMS sensors and uses standard valve stems for straightforward installation.
