Performance Specs
- Internal Step-Up Ratio: 3.45:1
- Max Speed: 55,000 RPM
- Max Boost: 21 PSI
- Max Flow: 1,050 CFM
- Max Power: 725 HP
- Peak Efficiency: 75%
Performance specs apply to units equipped with heavy duty gearcase.
Dimensions
- Discharge OD: 2.75"
- Inlet OD: 3.5"
- Discharge ID: 2.38"
- Inducer Diameter: 3.1"
- Straight cut spur gear
- Available with straight or curved discharge
