ProCharger Air-to-Water (Ice Water) Race Intercooler - Same Side Inlet & Outlet - 4 Inch - 1800 HP - WI1005A-001
Extreme Air-to-Water Race Intercooler for 1,800 HP Forced Induction Builds
The ProCharger WI1005A-001 Air-to-Water (Ice Water) Race Intercooler is designed for the most demanding custom supercharger and turbocharger applications where maximum cooling performance is essential. Featuring a same side inlet and outlet configuration with massive 4-inch air connections, this intercooler is capable of supporting applications producing up to 1,800 horsepower, making it ideal for drag racing, street outlaw, standing mile, and other extreme four-digit horsepower combinations.
Unlike traditional air-to-air intercoolers, this air-to-water (ice water) design uses a dedicated coolant circuit to rapidly extract heat from the compressed intake charge. When paired with an appropriately sized water pump, reservoir, and ice water system, it delivers exceptionally low intake air temperatures for maximum horsepower consistency during repeated high-boost runs.
Built for Maximum Cooling Capacity
The WI1005A-001 utilizes a durable sheet metal construction surrounding a deep, high-capacity core measuring 9 inches wide, 13 inches tall, and 19 inches deep. Its substantial core volume provides outstanding thermal efficiency while maintaining a compact frontal footprint, making it well suited for custom race chassis where packaging is critical.
The same side inlet and outlet configuration simplifies charge pipe routing for many race applications, while the oversized 4-inch air connections provide the airflow capacity required for extreme horsepower combinations with minimal restriction.
Features
- Designed for custom supercharger and turbocharger race applications
- Supports up to approximately 1,800 horsepower
- Air-to-water (ice water) intercooler design for maximum cooling efficiency
- Heavy-duty sheet metal construction
- Same side inlet and outlet configuration
- Oversized 4-inch inlet and outlet diameter
- Deep 19-inch core for exceptional heat rejection
- Compact frontal dimensions for easier packaging in custom race vehicles
- Helps maintain extremely low intake air temperatures during high-boost operation
Quick Specs
- Part Number: WI1005A-001
- Manufacturer: ProCharger
- Product Type: Air-to-Water (Ice Water) Race Intercooler
- Construction: Sheet Metal
- Inlet/Outlet Location: Same Side
- Inlet/Outlet Diameter: 4 inches
- Maximum Horsepower: 1,800 HP
- Core Width: 9 inches
- Core Height: 13 inches
- Core Depth: 19 inches
- Application: Universal custom race applications
- Cooling Type: Air-to-Water (Ice Water)
Why Choose the WI1005A-001?
For extreme horsepower applications, intake air temperature control is critical to making consistent power. The WI1005A-001 combines ProCharger's race-proven air-to-water technology with oversized 4-inch airflow capacity and a deep-core design to deliver exceptional cooling performance. It's an excellent solution for builders pushing well beyond four-digit horsepower where every degree of intake air temperature matters.
FAQs
Is this intercooler intended for race applications?
Yes. The WI1005A-001 is designed primarily for custom high-performance and racing applications where an air-to-water intercooling system provides the greatest cooling efficiency.
Why choose an air-to-water intercooler for extreme horsepower?
Air-to-water intercoolers offer exceptional cooling efficiency in a compact package and can utilize chilled or ice water in racing environments to dramatically reduce intake air temperatures during high-boost operation.
Why Buy from Beefcake Racing?
At Beefcake Racing, we specialize in ProCharger systems, custom forced induction builds, and race-proven performance components. Whether you're building a drag car, standing mile machine, or another extreme horsepower project, our experienced team can help you select the right intercooling solution for your combination.
