ProCharger Air-to-Air Front Cross Flow Intercooler - Front Inlet/Outlet - 3 Inch - 1000 HP - AIGU1A-001
Front Cross Flow Air-to-Air Intercooler for 1,000 HP Forced Induction Builds
The ProCharger AIGU1A-001 Air-to-Air Front Cross Flow Intercooler is engineered for custom supercharger and turbocharger applications that require exceptional airflow and cooling capacity. Featuring a front cross flow inlet and outlet configuration with 3-inch inlet and outlet connections, this intercooler is designed to support applications producing up to 1,000 horsepower.
Constructed with a rugged bar-and-plate core and durable sheet metal end tanks, the AIGU1A-001 efficiently removes heat from compressed intake air before it reaches the engine. Cooler, denser intake air helps improve horsepower consistency, reduce heat soak, and enhance reliability during prolonged high-boost operation.
Front Cross Flow Design for Custom Installations
Unlike traditional side-entry intercoolers, the front cross flow inlet and outlet configuration provides additional flexibility for charge pipe routing in custom engine bays. Combined with its 34-inch wide core and substantial 4.5-inch thickness, the AIGU1A-001 offers outstanding cooling efficiency while accommodating unique installation requirements.
Whether you're fabricating a custom ProCharger installation or designing a high-performance turbocharged system, this intercooler delivers the airflow and thermal capacity required for serious four-digit horsepower combinations.
Features
- Designed for custom supercharger and turbocharger applications
- Supports up to approximately 1,000 horsepower
- Heavy-duty bar-and-plate intercooler core
- Durable sheet metal end tanks
- Front cross flow inlet and outlet configuration
- 3-inch inlet and outlet diameter
- Large 34-inch wide core for excellent cooling efficiency
- 4.5-inch thick core for increased heat rejection
- Helps reduce intake air temperatures for improved horsepower consistency and engine reliability
Quick Specs
- Part Number: AIGU1A-001
- Manufacturer: ProCharger
- Product Type: Air-to-Air Front Cross Flow Intercooler
- Core Construction: Bar-and-Plate
- End Tank Construction: Sheet Metal
- Inlet/Outlet Location: Front Cross Flow
- Inlet/Outlet Diameter: 3 inches
- Maximum Horsepower: 1,000 HP
- Core Width: 34 inches
- Core Height: 9 inches
- Core Depth: 4.5 inches
- Application: Universal custom forced induction applications
Why Choose the AIGU1A-001?
The AIGU1A-001 is an excellent solution for custom applications where a front cross flow configuration offers the best plumbing layout. Its large bar-and-plate core provides the cooling capacity required for 1,000 HP combinations while maintaining excellent airflow and helping deliver consistent performance under demanding boost conditions.
FAQs
Is this intercooler vehicle specific?
No. The AIGU1A-001 is a universal air-to-air intercooler intended for custom fabrication and forced induction applications.
What is the advantage of a front cross flow intercooler?
A front cross flow configuration can simplify charge pipe routing in certain custom builds, providing additional installation flexibility while maintaining excellent cooling efficiency for high-performance forced induction systems.
