ProCharger Air-to-Air Intercooler - Same Side Inlet/Outlet - 4 Inch - 1550 HP - AI006A-002
Maximum Capacity Same Side Air-to-Air Intercooler for 1,550 HP Forced Induction Builds
The ProCharger AI006A-002 Air-to-Air Intercooler is engineered for extreme custom supercharger and turbocharger applications that demand maximum airflow and exceptional charge-air cooling while utilizing a same side inlet and outlet configuration. Featuring massive 4-inch inlet and outlet connections, this intercooler is designed to support applications producing up to 1,550 horsepower, making it the ideal choice for serious drag racing, standing mile, street outlaw, and other four-digit horsepower builds. :contentReference[oaicite:0]{index=0}
Constructed with a heavy-duty bar-and-plate core and durable sheet metal end tanks, the AI006A-002 efficiently removes heat from compressed intake air before it enters the engine. Cooler, denser intake air helps improve horsepower consistency, minimize heat soak, and enhance engine reliability during sustained high-boost operation.
Same Side Configuration with Maximum Airflow
The same side inlet and outlet layout simplifies charge pipe routing by keeping both connections on one side of the intercooler, making fabrication easier for many custom engine bay layouts. Combined with its massive 27-inch wide by 12-inch tall core, an ultra-thick 6-inch core, and oversized 4-inch inlet and outlet connections, the AI006A-002 delivers exceptional cooling efficiency while minimizing airflow restriction. :contentReference[oaicite:1]{index=1}
Whether you're fabricating a custom ProCharger installation or assembling an extreme turbocharged combination, this intercooler provides the airflow capacity and heat rejection required for the most demanding forced induction applications.
Features
- Designed for custom supercharger and turbocharger applications
- Supports up to approximately 1,550 horsepower
- Heavy-duty bar-and-plate intercooler core
- Durable sheet metal end tanks
- Same side inlet and outlet configuration
- Oversized 4-inch inlet and outlet connections
- Massive 6-inch thick core for maximum cooling capacity
- Large 27-inch core provides exceptional heat rejection
- Helps reduce intake air temperatures for improved horsepower consistency and engine reliability
Quick Specs
- Part Number: AI006A-002
- Manufacturer: ProCharger
- Product Type: Air-to-Air Intercooler
- Core Construction: Bar-and-Plate
- End Tank Construction: Sheet Metal
- Inlet/Outlet Location: Same Side
- Inlet/Outlet Diameter: 4 inches
- Maximum Horsepower: 1,550 HP
- Core Width: 27 inches
- Core Height: 12 inches
- Core Depth: 6 inches
- Application: Universal custom forced induction applications
Why Choose the AI006A-002?
When your combination reaches extreme horsepower levels, intercooler efficiency becomes critical. The AI006A-002 combines ProCharger's proven bar-and-plate construction with oversized 4-inch charge pipe connections and a massive 6-inch thick core to maximize airflow while delivering outstanding heat rejection. The result is cooler intake temperatures, improved resistance to heat soak, and dependable performance under the most demanding boost conditions.
FAQs
Is this intercooler vehicle specific?
No. The AI006A-002 is a universal air-to-air intercooler intended for custom fabrication and forced induction applications.
Why does this intercooler use 4-inch inlet and outlet connections?
The oversized 4-inch connections are designed for extreme horsepower combinations where maximum airflow and minimal restriction are essential for achieving peak performance.
