ProCharger Air-to-Air Intercooler - Opposite Side Inlet/Outlet - 4 Inch - 1550 HP - AI006A-001
Extreme-Duty Air-to-Air Intercooler for 1,550 HP Forced Induction Builds
The ProCharger AI006A-001 Air-to-Air Intercooler is built for the most demanding custom supercharger and turbocharger applications where maximum airflow and cooling efficiency are critical. Featuring opposite-side 4-inch inlet and outlet connections, this intercooler is engineered to support applications producing up to 1,550 horsepower, making it ideal for serious drag racing, standing mile, street outlaw, and other extreme-performance builds.
Constructed around a massive bar-and-plate core with heavy-duty sheet metal end tanks, the AI006A-001 efficiently dissipates heat from compressed intake air before it reaches the engine. Cooler intake temperatures help improve horsepower consistency, reduce heat soak, and provide greater reliability during prolonged high-boost operation.
Engineered for Maximum Airflow
Designed for combinations where airflow is just as important as cooling capacity, the AI006A-001 features oversized 4-inch inlet and outlet connections paired with a massive 6-inch thick core. This combination minimizes restriction while maximizing heat rejection, making it an outstanding choice for four-digit horsepower applications that require exceptional charge-air cooling.
The opposite-side inlet and outlet configuration simplifies charge pipe routing for many custom front-mounted intercooler installations while maintaining efficient airflow through the core.
Features
- Designed for custom supercharger and turbocharger applications
- Supports up to approximately 1,550 horsepower
- Heavy-duty bar-and-plate intercooler core
- Durable sheet metal end tanks
- Opposite-side inlet and outlet configuration
- Oversized 4-inch inlet and outlet connections for maximum airflow
- Massive 6-inch thick core for exceptional cooling capacity
- Helps reduce intake air temperatures for improved horsepower consistency and engine reliability
Quick Specs
- Part Number: AI006A-001
- Manufacturer: ProCharger
- Product Type: Air-to-Air Intercooler
- Core Construction: Bar-and-Plate
- End Tank Construction: Sheet Metal
- Inlet/Outlet Location: Opposite Sides
- Inlet/Outlet Diameter: 4 inches
- Maximum Horsepower: 1,550 HP
- Core Width: 27 inches
- Core Height: 12 inches
- Core Depth: 6 inches
- Application: Universal custom forced induction applications
Why Choose the AI006A-001?
When your combination reaches extreme horsepower levels, intercooler performance can make the difference between repeatable power and excessive heat soak. The AI006A-001 combines ProCharger's proven bar-and-plate construction with oversized 4-inch charge pipe connections and an ultra-deep 6-inch core to deliver maximum cooling capacity and airflow for the most demanding forced induction combinations.
FAQs
Is this intercooler vehicle specific?
No. The AI006A-001 is a universal air-to-air intercooler intended for custom fabrication and forced induction applications.
Why does this intercooler use 4-inch inlet and outlet connections?
The oversized 4-inch connections are designed for extreme horsepower combinations where maximum airflow and reduced charge pipe restriction are essential for achieving peak performance.
