Vortech Superchargers Tuner Kit w/ V-3 Si-Trim - Black (2018-2020 Ford F-150 5.0L) 4FV218-314L
Black V-3 Si-Trim Supercharger Tuner Kit for 2018-2020 F-150 5.0L
The Vortech Superchargers Tuner Kit with V-3 Si-Trim (PN 4FV218-314L) is purpose-built for 2018-2020 Ford F-150 trucks equipped with the 5.0L Coyote engine. Finished in black, this tuner kit delivers Vortech's most advanced street centrifugal supercharger technology while giving experienced builders full control over fueling and calibration.
Featuring the V-3 Si-Trim self-lubricated supercharger paired with an air-to-air charge cooler, this system is capable of boosting a stock 5.0L F-150 to an estimated ~606 horsepower and ~596 lb-ft of torque at 8-10 PSI on 91-octane fuel (results vary with tuning and supporting modifications). Vortech's lightweight, high-efficiency design helps deliver strong gains without the mass or heat penalties of less efficient forced-induction alternatives.
V-3 Si-Trim Supercharger Technology
The V-3 Si-Trim represents Vortech's latest evolution in centrifugal supercharging, incorporating a patented oil control system and a state-of-the-art compressor stage. With industry-leading 78% adiabatic efficiency (SAE J1723), the V-3 Si-Trim generates less heat, reduces parasitic loss, and produces more net power - while remaining exceptionally durable.
Its self-contained lubrication system eliminates the need for engine oil plumbing, simplifying installation and long-term maintenance - an ideal solution for modern F-150 performance builds.
Performance & Efficiency
- Estimated Output: ~606 HP / ~596 lb-ft (application and tuning dependent)
- Boost Pressure: 8-10 PSI
- Efficiency: High-efficiency centrifugal design for reduced heat and drive loss
- Weight Advantage: Significantly lighter than many competing supercharger designs
Tuner Kit Configuration
This Tuner Kit includes all major supercharger hardware but does not include fuel system upgrades or ECU calibration. This allows custom tuners to select injectors, pumps, and engine management tailored to their specific power goals.
Included Components & Features
- Vortech V-3 Si-Trim self-lubricated centrifugal supercharger with 3.80" drive pulley
- Billet aluminum supercharger mounting bracket assembly with idlers
- Drive belt and high-grade mounting hardware
- Air inlet assembly with mandrel-bent 3.5" aluminum tubing
- High-flow roto-molded inlet duct compatible with OEM air box and select aftermarket CAIs
- Welded air-to-air charge cooler
- Mandrel-bent 3" aluminum discharge tubing
- Silicone couplers and premium stainless-steel clamps
- Recirculating bypass valve for surge-free operation
Optional Upgrades
- Vortech Maxflow Race Blow-Off Valve upgrade assemblies
Installation Notes
- Estimated installation time: 6-9 hours
- Professional installation and custom tuning strongly recommended
Quick Specs
- Manufacturer: Vortech Superchargers
- Part Number: 4FV218-314L
- Vehicle: Ford F-150
- Model Years: 2018, 2019, 2020
- Engine: 5.0L Coyote V8
- System Type: Supercharger Tuner Kit
- Supercharger: V-3 Si-Trim (self-lubricated)
- Charge Cooling: Air-to-Air
- Finish: Black
Fitment
- 2018 Ford F-150 5.0L
- 2019 Ford F-150 5.0L
- 2020 Ford F-150 5.0L
Emissions & Legal Notice
- NOT AVAILABLE OR LEGAL FOR SALE IN CALIFORNIA
- For off-road and competition use only
- Installation on emissions-controlled vehicles driven on public roads may violate U.S. federal emissions law
