FuelTech External MAP Sensor - 10 BAR - Black Composite - Includes Mating Plug Kit - 5005100190 / 5005100023
10 Bar External MAP Sensor with Plug Kit for High-Boost Applications
The FuelTech External MAP Sensor - 10 BAR is designed for high-performance engines that exceed the limits of standard internal MAP sensors. Capable of measuring up to 135.3 PSI of boost pressure, this sensor provides the critical intake manifold data needed to maintain accurate fueling and engine control under extreme conditions.
Whether you're pushing serious boost in a turbo or supercharged setup, this sensor ensures your ECU receives precise manifold air pressure readings to maintain the optimal air to fuel ratio for efficient combustion and maximum power.
Complete Kit with Mating Plug for Easy Installation
This version includes a mating plug kit, making installation simple while ensuring a secure and reliable electrical connection. It is ideal for both new builds and upgrading existing setups.
- Includes connector for proper sensor wiring
- Ensures secure, vibration-resistant connections
- Perfect for custom harness builds or replacements
- Reduces installation time and wiring complexity
Designed to Expand Beyond Internal MAP Sensor Limits
All FuelTech PowerFT ECUs include a 7 BAR internal MAP sensor, but high-boost applications require more range. This 10 BAR external sensor provides the additional headroom needed for extreme builds.
- Extends MAP measurement beyond internal ECU limits
- Ideal for high-boost turbo and supercharger setups
- Ensures accurate fueling at elevated boost levels
- Supports advanced tuning and performance optimization
Stable Signal Output for ECU Integration and Data Logging
The sensor features a 0.5-4.5V linear analog output, ensuring seamless compatibility with FuelTech ECUs and most aftermarket standalone engine management systems. This stable signal allows for precise data logging and reliable tuning adjustments.
- Consistent signal for accurate ECU input
- Supports real-time boost monitoring and tuning
- Enables precise air to fuel ratio control
- Improves engine safety and performance under boost
Black Composite Construction for Lightweight Durability
Built with a black composite housing, this sensor offers a lightweight yet durable solution for high-performance environments. It is engineered to handle extreme pressure conditions while maintaining long-term reliability.
- Lightweight black composite construction
- Designed for high-pressure intake system monitoring
- Durable and reliable in motorsports applications
- 1/8 inch NPT thread for easy installation
Features
- 10 BAR external MAP sensor for high-boost applications
- Includes mating plug kit for wiring
- Measures up to 135.3 PSI of boost pressure
- 0.5-4.5V linear analog output
- Compatible with FuelTech and aftermarket ECUs
- Extends beyond 7 BAR internal MAP sensor limits
- Black composite housing for lightweight durability
- 1/8 inch NPT thread for universal installation
Quick Specs
- Brand: FuelTech
- Product Type: External MAP Sensor with Plug Kit
- Pressure Range: -14.7 psi to +135.3 psi (0-150 psi absolute)
- Output Signal: 0.5-4.5V
- Supply Voltage: 5V
- Thread Size: 1/8 inch NPT
- Material: Black Composite
- Applications: Intake manifold pressure and boost monitoring
- Connector Pinout: A - Ground / B - 5V / C - Signal
- Part Number: 5005100190 / 5005100023
FAQs
What is included in this MAP sensor kit?
This kit includes the 10 BAR external MAP sensor and a mating plug connector, ensuring proper installation and wiring.
When should I upgrade to a 10 BAR MAP sensor?
You should upgrade when your boost levels exceed the range of your ECUs internal MAP sensor, such as in high-boost turbo or supercharged applications.
