Vortech Supercharger V-2 Si Tuner System - High Output - Polished (2007-2009 Mustang V6) 4FU218-748SQ
Polished V-2 Si-Trim High Output Tuner Supercharger System for 2007-2009 Mustang V6
The Vortech Superchargers V-2 Si-Trim High Output Tuner System (PN 4FU218-748SQ) is engineered for 2007-2009 Ford Mustang V6 models equipped with the 4.0L engine. Featuring a show-quality polished finish, this system delivers Vortech's proven centrifugal supercharger performance in a high-output tuner configuration designed for custom fueling and professional calibration.
This is a true tuner system, supplied without fuel system upgrades or ECM reprogramming, making it ideal for racers and advanced builders who want complete control over fueling, boost strategy, and engine management.
High Output Performance Overview
The 2007-2009 Mustang V6 comes from the factory with approximately 210 horsepower and 254 lb-ft of torque. Vortech's High Output supercharger configuration, when paired with an air-to-water Charge Cooler and proper tuning, is capable of increasing horsepower from 210 to 330 and torque from 240 lb-ft to 337 lb-ft.
This makes the High Output tuner system well suited for aggressive street builds, track use, and competition applications where sustained performance under higher boost is required.
V-2 Si-Trim Supercharger Technology
The V-2 Si-Trim centrifugal supercharger features Vortech's technologically advanced, high-efficiency impeller and compressor housing, developed in Vortech's supercharger test cell. A gear-driven design with SQ technology delivers nearly silent operation while maintaining excellent reliability.
The V-2 series utilizes an engine oil-integrated lubrication system, making it a strong choice for continued-use applications such as road racing, where oil cooling or filtration can be added as needed.
Included Components & Features
- V-2 Si-Trim centrifugal supercharger (High Output tuner configuration)
- Gear-driven supercharger with SQ technology for quiet operation
- High-efficiency impeller and compressor housing developed in Vortech's test cell
- Provision for integrated air-to-water Charge Cooler systems (High Output setups)
- Heat-resistant silicone inlet and discharge connections with stainless steel clamps
- Billet aluminum mounting bracket for strength, rigidity, and clean appearance
- High-flow bypass valve for surge-free compressor operation
- Note: Systems are also available with V-3 series self-lubricating superchargers (no oil lines required)
Tuner System Configuration Explained
Tuner systems include all primary supercharger hardware but intentionally exclude fuel injectors, fuel pumps, and ECU programming. This allows professional tuners to select supporting components and calibration that best match the vehicle's build and performance goals.
Installation Notes
- Professional installation and custom tuning required
- Fuel system components and ECU calibration not included
Quick Specs
- Manufacturer: Vortech Superchargers
- Part Number: 4FU218-748SQ
- Application: 2007-2009 Ford Mustang V6 4.0L
- System Type: Tuner Supercharger System (High Output)
- Supercharger: V-2 Si-Trim (Engine Oil Integrated)
- Finish: Polished
Emissions & Legal Notice
- NOT AVAILABLE OR LEGAL FOR SALE IN CALIFORNIA
- Tuner kits are NOT CARB legal and are legal in California only for racing vehicles which may never be used, or registered or licensed for use, upon a highway (off-road use only)
- The manufacture, sale, offer for sale, or installation of this product may also be illegal under the federal clean air act (42 U.S.C. 7522(A)(3))
- Installation on vehicles driven on public roads is likely to violate U.S. emissions law
Warranty Information
- 1-Year Supercharger Limited Warranty (tuner systems only)
- 3-Year Supercharger Limited Warranty available with V-3 superchargers when purchased as part of a complete street-legal system (additional cost)
FAQs
- Does this High Output tuner system include a Charge Cooler?
No. Charge Cooler components, fuel system upgrades, and ECU tuning are not included. - What is the advantage of the High Output configuration?
It supports higher boost levels and air-to-water Charge Cooler integration for significantly increased horsepower and torque potential.
Fitment
- 2007 Ford Mustang V6 4.0L
- 2008 Ford Mustang V6 4.0L
- 2009 Ford Mustang V6 4.0L
