Vortech Superchargers Tuner Kit - V-2 Si-Trim - Satin - No Charge Cooler (2000-2004 Mustang GT 4.6L 2V) 4FL218-150SQ
Satin V-2 Si-Trim Tuner Supercharger Kit for 2000-2004 Mustang GT
The Vortech Superchargers Tuner Kit with V-2 Si-Trim (PN 4FL218-150SQ) is a race-intended centrifugal supercharger package designed for 2000-2004 Ford Mustang GT models equipped with the 4.6L 2-valve engine. This kit features a satin-finish, engine oil-fed V-2 Si-Trim supercharger and is supplied without a Charge Cooler, making it ideal for experienced builders and professional tuners who want full control over fueling, calibration, and boost strategy.
With appropriate supporting modifications and custom tuning, Vortech indicates this configuration can safely support increases from 260 horsepower to 402 horsepower and torque from 302 lb-ft to 400 lb-ft. Power delivery remains smooth and progressive, characteristic of Vortech's centrifugal design.
V-2 Si-Trim Supercharger Technology
The V-2 Si-Trim centrifugal supercharger uses Vortech's high-efficiency impeller and housing design developed in their supercharger test cell. The V-2 platform employs an engine oil-fed lubrication system, allowing oil to be cooled and filtered through the engine - an advantage for sustained boost and extended high-load operation.
Vortech's SQ (Super Quiet) gear-driven technology provides excellent durability and reliability while maintaining near-silent operation.
Tuner Kit Configuration Explained
This is a tuner kit, meaning it includes the complete supercharger head unit, mounting brackets, drive system, and related hardware, but does not include fuel system upgrades or ECM reprogramming. This allows the tuner or racer to select injectors, fuel delivery components, and engine management best suited to the specific engine build and performance goals.
Because this kit is supplied without a Charge Cooler, intake air temperature management is left to the installer, making this configuration best suited for custom or competition-focused applications.
Performance & System Features
- V-2 Si-Trim centrifugal supercharger with engine oil-fed lubrication
- Satin supercharger finish
- Vortech SQ gear-driven technology for quiet, reliable operation
- High-efficiency impeller and housing developed in Vortech's supercharger test cell
- OEM-type aluminum mounting bracket for factory-installed appearance and rigidity
- High-flow bypass valve for surge-free compressor operation
- Heat-resistant silicone inlet and discharge sleeves
- Premium stainless steel clamps
- Complete supercharger drive system with required pulleys and hardware
Installation Notes
- Estimated installation time: approximately 12 hours
- Professional installation and custom tuning strongly recommended
- Fuel system upgrades and ECM calibration are required but not included
Quick Specs
- Manufacturer: Vortech Superchargers
- Part Number: 4FL218-150SQ
- Application: 2000-2004 Ford Mustang GT 4.6L 2V
- Kit Type: Tuner Kit
- Supercharger: V-2 Si-Trim
- Lubrication: Engine oil-fed
- Finish: Satin
- Charge Cooling: None (No Charge Cooler)
- Advertised Output Capability: Up to 402 HP with proper tuning and supporting modifications
- Hardware Kit: 4FL100-001 (spare/replacement mounting hardware)
Emissions & Legal Notice
- NOT AVAILABLE OR LEGAL FOR SALE IN CALIFORNIA
- Tuner kits are not CARB legal
- Legal in California only for racing vehicles that are never registered or driven on public highways
- Installation on emissions-controlled vehicles may violate U.S. federal emissions law (42 U.S.C. 7522(a)(3))
FAQs
- What makes this a tuner kit?
This kit excludes fuel system components and ECM calibration, allowing for fully custom tuning and fuel system selection. - Is this kit street legal?
No. This tuner kit is not CARB compliant and is intended strictly for off-road and racing applications.
Fitment
- 2000 Ford Mustang GT 4.6L 2V
- 2001 Ford Mustang GT 4.6L 2V
- 2002 Ford Mustang GT 4.6L 2V
- 2003 Ford Mustang GT 4.6L 2V
- 2004 Ford Mustang GT 4.6L 2V
