Vortech Tuner Kit w/ V-3 Si-Trim - Polished - With Charge Cooler (1996-1998 4V 4.6 Mustang Cobra) 4FK218-118L
Polished V-3 Si-Trim Charge-Cooled Tuner Supercharger Kit for 1996-1998 Mustang Cobra 4.6L 4V
The Vortech Superchargers Tuner Kit (PN 4FK218-118L) is a charge-cooled tuner supercharger system designed specifically for 1996-1998 Ford Mustang Cobra models equipped with the 4.6L 4-valve DOHC V8. This configuration combines a polished V-3 Si-Trim internally lubricated centrifugal supercharger with Vortech's air-to-water charge cooler system, providing the airflow efficiency and intake-air temperature control required for serious high-performance Cobra builds.
This exact part number DOES include a charge cooler. It is still classified as a tuner kit, meaning fuel system components and ECM calibration are intentionally excluded so experienced tuners can tailor injectors, pumps, and tuning to their specific horsepower goals.
What This Part Number Is (and Is Not)
- This kit IS: Tuner kit, V-3 Si-Trim, polished finish, WITH air-to-water charge cooler (PN 4FK218-118L)
- This kit is NOT: A complete, street-legal supercharger system
- This kit is NOT: A non-charge-cooled tuner kit
- This kit is NOT: CARB-compliant or emissions legal
V-3 Si-Trim Supercharger Technology
The V-3 Si-Trim features Vortech's self-contained internal lubrication system, eliminating the need for engine oil feed and return lines. The SQ (Super Quiet) gear drive delivers smooth, quiet operation while maintaining excellent airflow efficiency and reliability.
The advanced impeller and compressor housing - developed in Vortech's supercharger test cell - support aggressive boost levels while minimizing heat generation and parasitic loss.
Integrated Air-to-Water Charge Cooler System
This tuner kit includes Vortech's integrated air-to-water, dual-pass charge cooler, which significantly increases intake-air density and supports higher boost operation. Vortech indicates charge-cooled High Output configurations for this Cobra platform can increase horsepower from 305 to 484 and torque from 285 lb./ft. to 423 lb./ft. when paired with appropriate supporting engine, fuel, and tuning modifications.
Important: Charge-cooled systems require a battery relocation kit (PN 8N150-010, sold separately).
Key Features
- Vortech V-3 Si-Trim centrifugal supercharger with internal lubrication
- Integrated air-to-water, dual-pass charge cooler
- High-efficiency impeller and housing developed in Vortech's test cell
- Heat-resistant silicone inlet and discharge couplers with stainless clamps
- OEM-style aluminum mounting bracket for factory-installed appearance
- High-flow bypass valve for smooth, surge-free compressor operation
Installation
- Estimated installation time: Approximately 10 hours
- Professional installation and custom tuning strongly recommended
Emissions & Legal Notice
- NOT AVAILABLE OR LEGAL FOR SALE IN CALIFORNIA
- Tuner kits are NOT CARB legal
- Legal in California only for off-road or racing vehicles never operated on public highways
- Installation on emissions-controlled vehicles may violate U.S. federal law (42 U.S.C. 7522(a)(3))
Additional Hardware
- Hardware Kit: 4FK100-004 (includes spare/replacement mounting hardware)
Tuner Kits & Supercharger Options
Tuner kits are identical to complete systems except they exclude fuel system upgrades and ECM reprogramming. This allows tuners and racers to configure fueling and calibration to match specific boost levels and power targets.
Vortech also offers alternative head units and configurations for different racing styles and duty cycles.
Quick Specs
- Manufacturer: Vortech Superchargers
- Part Number: 4FK218-118L
- Application: 1996 Ford Mustang Cobra 4.6L 4V; 1997 Ford Mustang Cobra 4.6L 4V; 1998 Ford Mustang Cobra 4.6L 4V
- Kit Type: Tuner Kit
- Supercharger: V-3 Si-Trim (internally lubricated)
- Finish: Polished
- Charge Cooling: Air-to-water, dual-pass (included)
- Estimated Install Time: ~10 hours
FAQs
- Does this tuner kit include a charge cooler?
Yes. PN 4FK218-118L includes Vortech's integrated air-to-water charge cooler system. - Is this system street legal?
No. This tuner kit is not CARB compliant and is intended strictly for off-road and racing use.
Fitment
- 1996 Ford Mustang Cobra 4.6L 4V
- 1997 Ford Mustang Cobra 4.6L 4V
- 1998 Ford Mustang Cobra 4.6L 4V
