Vortech V-1 Heavy Duty Ti-Trim Supercharger Head Unit - CCW Rotation - Straight Discharge - Black Finish 2A139-124
Black V-1 Heavy Duty Ti-Trim Centrifugal Supercharger Head Unit
The Vortech V-1 Heavy Duty Ti-Trim Supercharger Head Unit (PN 2A139-124) is a proven solution for street/strip vehicles with modified engines that demand strong airflow capacity, durability, and consistent performance under boost. This configuration features counter-clockwise (CCW) rotation with a straight discharge outlet, making it ideal for applications requiring direct discharge routing and flexible mounting layouts.
Built around a heavy-duty gear case and Vortech's Ti-Trim compressor design, this head unit is engineered to support elevated boost levels and sustained RPM operation while delivering predictable, repeatable power for aggressive street and strip builds.
V-1 Heavy Duty Ti-Trim Technology
The Ti-Trim utilizes a straight-cut spur gear drive designed for strength and reliable power transfer under high load. This Heavy Duty configuration is well suited for high-output engines where durability and airflow capacity are critical.
Performance Capabilities
- Maximum Power Capability: 950 HP
- Maximum Boost: 26 PSI
- Maximum Airflow: 1,400 CFM
- Peak Efficiency: 75%
- Maximum Supercharger Speed: 55,000 RPM
- Internal Step-Up Ratio: 3.45:1
Performance specifications apply to units equipped with the heavy-duty gear case.
Dimensions
- Discharge OD: 2.75"
- Discharge ID: 2.38"
- Inlet OD: 3.75"
- Inducer Diameter: 3.51"
- Overall Size: 8.75" W × 9.44" H × 5.52" D (not including input shaft)
Application Notes
The V-1 Heavy Duty Ti-Trim is an excellent choice for street/strip vehicles with modified engines seeking high airflow capability without stepping into larger race-only supercharger platforms. Drive pulley not included.
Quick Specs
- Manufacturer: Vortech Superchargers
- Part Number: 2A139-124
- Supercharger Model: V-1 Heavy Duty Ti-Trim
- Rotation: Counter-Clockwise (CCW)
- Discharge Style: Straight Discharge
- Gear Type: Straight-Cut Spur Gear
- Gear Case: Heavy Duty
- Finish: Black
Emissions & Legal Notice
- NOT AVAILABLE OR LEGAL FOR SALE IN CALIFORNIA
- For off-road and competition use only
- Installation on emissions-controlled vehicles driven on public roads may violate U.S. federal emissions law
