ProCharger High Output Cog Drive Race Supercharger Kit F-2 - V-Belt Accessories - No Intercooler (Small Block Chevy) - 1CA200-F2
Extreme Cog-Driven Boost for Small Block Chevy Race Builds
The ProCharger High Output Cog Drive Race Supercharger Kit with F-2 head unit is built for Small Block Chevy (SBC) applications targeting serious performance in the 1000-1450 horsepower range. Designed for high-horsepower race and street builds, this system delivers consistent, repeatable boost using a 50mm cog drive belt that eliminates slip under extreme load.
This setup allows builders to make big power while still retaining key accessories like power steering, making it a versatile solution for aggressive builds.
50mm Cog Drive System for Maximum Boost Consistency
The 50mm-wide cog belt drive is engineered for durability and precision, ensuring reliable power transfer and consistent boost delivery.
- 50mm cog belt for high horsepower durability
- Eliminates belt slip under high boost conditions
- Consistent boost delivery at high RPM
- Ideal for race and high-output SBC applications
F-2 Head Unit - High Airflow for Serious Horsepower
The included F-2 ProCharger head unit is designed for high airflow and strong top-end performance, making it well-suited for extreme horsepower combinations.
- High-efficiency centrifugal supercharger design
- Strong airflow capability for high-output builds
- Designed for race and high-performance applications
- Supports aggressive horsepower goals
V-Belt Accessory Compatibility for Traditional SBC Setups
This configuration is designed for V-belt accessory drives, making it ideal for classic Small Block Chevy builds while still supporting modern performance upgrades.
- Compatible with V-belt accessory systems
- Allows retention of power steering and key accessories
- Flexible for custom installations
- Accessory configuration must be specified when ordering
Self-Contained Oiling System for Simplified Installation
The self-contained oiling system eliminates the need for external oil lines, improving installation simplicity and long-term reliability.
- No external oil feed or return lines required
- Cleaner engine bay layout
- Reduced installation complexity
- Supports optional intercooler upgrades
Built for Custom High-Horsepower Applications
This is a universal race system intended for custom Small Block Chevy builds. The included tubing kit is not vehicle-specific, allowing flexibility across a wide range of engine bay configurations.
Performance Highlights
- Supports 1000-1450 horsepower applications
- 50mm cog drive system eliminates belt slip
- F-2 head unit for high airflow performance
- Designed for Small Block Chevy race builds
- Allows accessory retention when properly configured
Key Features
- ProCharger F-2 centrifugal supercharger
- 50mm cog-style drive system
- V-belt accessory drive compatibility
- Self-contained oiling system
- Universal tubing kit included
- Designed for carbureted or EFI blow-through setups
- Supports extreme horsepower race applications
- Made in the USA
Available Options
- Satin, black, or polished finishes for supercharger, brackets, and carb bonnet
- Supercharger upgrades up to F-3
- Intercooler upgrade options
- Bypass valve upgrades
- Fuel system upgrades
- Repositioning bracket for alternate mounting configurations
Installation and Compatibility Notes
- Carbureted systems require 4150-style or similar blow-through carburetor or EFI throttle body (sold separately)
- Fuel system upgrades required (sold separately)
- Universal tubing kit is not vehicle-specific
- Electric water pump recommended for V-belt accessory drive
- Mechanical water pump required for serpentine systems (short style)
- Must supply GM Type II power steering pump with remote reservoir
- A/C option available for serpentine systems only using Sanden 508/SD5H14 compressor
- Serpentine systems require standard rotation water pump (SBC 1984-1991 Corvette reverse rotation, BBC Edelbrock 8854 or similar)
- Alternator placement may not be compatible with some aftermarket EFI systems
- Designed for Delco-style alternator with 6.61 inch mounting spacing
Quick Specs
- Manufacturer: ProCharger
- Product Type: High Output Cog Drive Race Supercharger Kit
- Supercharger: F-2
- Drive System: 50mm Cog Belt
- Accessory Drive: V-Belt
- Intercooler: Not Included
- Horsepower Capability: 1000-1450 HP
- Engine Application: Small Block Chevy (SBC)
- Oiling System: Self-contained
- Tubing: Universal (non vehicle-specific)
- Fuel System: Upgrade required
- Part Number: 1CA200-F2
FAQs
Is the F-2 head unit suitable for extreme horsepower builds?
Yes, the F-2 head unit is designed for high airflow and strong performance, making it well-suited for aggressive high-horsepower applications.
Does this system include an intercooler?
No, this configuration does not include an intercooler, but intercooler upgrades are available as an option for higher efficiency setups.
