Paxton NOVI 1500 Supercharger System - PowerHat & Discharge - Satin (Big Block Mopar Carbureted) 1201860
Satin NOVI 1500 Supercharger System for Carbureted Big Block Mopar 440 RB
The Paxton NOVI 1500 Supercharger System is a universal, carbureted centrifugal supercharger package engineered specifically for Big Block Mopar 440 RB engines. Designed for builders looking to add reliable, streetable boost with strong mid- and top-end power, this satin-finish system delivers proven Paxton performance in a flexible, application-driven configuration.
With the supplied pulley ratio, the NOVI 1500 produces approximately 5-6 PSI at 6,000 RPM on a lightly modified 440 cubic-inch engine. Depending on boost level, engine volumetric efficiency, and supporting components, typical horsepower gains fall in the 30-75%+ range, making this system an excellent foundation for serious big block Mopar street and strip builds.
Key Features & Performance Highlights
- Paxton NOVI 1500 centrifugal supercharger (clockwise rotation, curved discharge)
- Produces approximately 5-6 PSI @ 6,000 RPM on a lightly modified 440ci engine
- Typical horsepower gains of 30-75%+ depending on configuration
- Satin finish for a clean, understated performance appearance
- Designed for OEM Dodge twin V-groove accessory crank pulley alignment
- Universal system ideal for custom carbureted big block Mopar applications
Included Components
- NOVI 1500 supercharger with 3.47-inch, 10-rib pulley
- Twin billet aluminum mounting plates with all required hardware
- Integrated manual belt tensioner with dual-bearing billet aluminum idler
- OEM alternator mounting provisions
- Supercharger drive assembly, including:
- 7.00-inch hard-anodized billet aluminum crank pulley
- 10-rib drive belt, spacers, and mounting hardware
- Supercharger oil feed assembly
- Supercharger oil drain assembly
- 4-inch aluminum inlet ducting with silicone sleeves, stainless clamps, and high-flow cone air filter
- 3.5-inch aluminum discharge tube with silicone sleeves and stainless clamps
- Cast aluminum carburetor hat / bonnet (PowerHat)
Carburetion & Fuel System Requirements
- Requires a properly prepared 4150-style carburetor with mechanical secondaries
- Demon carburetors may also be used with appropriate preparation
- High-volume, boost-referenced fuel pump and regulator required (not included)
- Carburetor re-jetting or minor modification may be required
Installation Notes
- Designed to work with OEM Dodge twin V-groove accessory crank pulley
- Vehicle throttle cable or linkage modifications may be required
- Replacement hood or hood modifications may be required depending on intake and bonnet configuration
- Accessory V-belts vary by application and pulley configuration
- Estimated installation time: 4-10 hours, depending on application
Optional Components & Upgrades
- Boost-referenced fuel pressure regulator
- Aftermarket ignition amplifier (recommended, not required)
- MSD 6AL-BTM ignition amplifier with timing retard (PN 5A101-014)
- Compressor bypass valves for higher boost applications
- Alternate supercharger and crank pulleys for custom boost levels
Quick Specs
- Manufacturer: Paxton Superchargers
- Part Number: 1201860
- Supercharger: NOVI 1500
- Rotation: Clockwise
- Discharge: Curved
- Kit Type: Complete Supercharger System
- Finish: Satin
- Boost Output: 5-6 PSI @ 6,000 RPM (440ci reference engine)
- Estimated Power Gain: 30-75%+
Emissions & Legal Notice
- NOT 50-state smog legal
- Intended for off-road and race-use-only vehicles
- Horsepower and torque figures are calculated estimates based on percentage increases
- Specifications are subject to change
FAQs
- Is a carburetor included with this system?
No. A properly prepared 4150-style carburetor or Demon carburetor must be supplied by the installer. - Does this kit include a fuel pump?
No. A high-volume, boost-referenced fuel pump and regulator are required and must be sourced separately.
